SWT25080H Handheld Automatic Electric Cable Tie Gun 0.7S Every Cable Tie
Handheld automatic cable tie gun can be used to wrap, tighten and cut off nylon cable ties by its own. Faster then by hand!
SWT25080H advantages
1. Use loose cable ties to bundle wire harness and other products. Cable ties size W2.5*L80mm. Model T25080.
2. With the smallest cable tie gun in the world.
3. Automatically wrap, tighten and cut off cable ties once touch the trigger.
4. 5 binding forces can be adjusted(2kg - 8kg).
5. Be suitable for assembly line operation.
6. With big touch screen, Chinese and English display. It is easy to manage and set parameters.
SWT25080H base data
| Product name | Automatic cable tie tool |
| Model | SWT25080H |
| Certificate | CE |
| Tool head | Handheld cable tie gun |
| Operation speed | 0.7S |
| Cable ties used in the machine | T25080, width 2.5mm * length 80mm |
| Cable tie thickness | 1.1mm |
| Cable tie tensile strength | 8kg |
| Bundle dia. | 2mm - 14mm |
| Pneumatic pressure | 5kg/cm² |
| Power supply | AC220 - 240V, 50/60Hz |
Applications
Vacumm cleaners wire harness, oven wiring, fans wiring harness, elevator wire harness, cables
Packing details
| Item | The host machine | The vibration bowl | Total |
| L * W * H/wooden case | L73 * W67 * H83cm | L66 * W52* H90cm | 0.73CBM |
| G.W./kg | 93kg | 65kg | 158kg |
Related products
| SWIFT auto cable tie tool- handheld cable tie gun |
| Model | SWT25080H | SWT25100H | SWT25120H | SWT36100H | SWT36120H | SWT36140H | SWT36150H |
| Cable ties(L* W)/mm | 80 * 2.5 | 100 * 2.5 | 120 * 2.5 | 100 * 3.6 | 120 * 3.6 | 140 * 3.6 | 150 * 3.6 |
| Binding Max Dia. | 14mm | 18mm | 22mm | 18mm | 23mm | 27mm | 31mm |
| Binding Min Dia. | 2mm | 3mm |
